TWIN WALL AIR GAP: COPPERLPLAST COPPER PLATED POLYPROPYLENE
PPs twin wall flue system copper plated exterior
The COPPERPLAST PPs-copper twin wall flue system is composed of rigid modular components, manufactured in enriched polypropylene with a minimum thickness of 1.5 mm and protected by an external wall in copper-effect stainless steel, compliant with CE marking according to the EN 14471 Euroopean standards. The modular components have a classic calibrated tongue-and-groove coupling with triple lip seal, compliant with European standard EN 14241-1. The system is suitable for extracting flue gases with a maximum operating temperature of up to 120 °C and a maximum pressure of 200 Pa.
DESIGNATIONS OF USE
|
CONDENSATION RESISTANT
|
YES |
|
|
INTERNAL WALL
|
PP | |
|
OUTER WALL
|
Copper |
|
|
INSULATION
|
Air Gap |
|
|
INSULATION THICKNESS
|
10 mm |
|
|
DIAMETERS
|
⌀ 60 ÷ 100 |
|
|
TEMPERATURE LEVEL
|
120 °C
|
|
|
PRESSURE LEVEL
|
H1 = 5000 Pa
|
|
 |
GAS APPLIANCES
|
NO
|
 |
GAS / DIESEL CONDENSING APPLIANCES
|
RECOMMENDED
|
 |
OIL APPLIANCES
|
NO
|
 |
WOOD-BURNING APPLIANCES
|
NO
|
 |
PELLET APPLIANCES
|
NO
|
 |
GAS COOKER HOODS
|
POSSIBLE
|
|
VENTILATION
|
POSSIBLE
|
 |
OUTDOOR INSTALLATION
|
RECOMMENDED
|
 |
INDOOR INSTALLATION
|
POSSIBLE
|
 |
INSTALLATION IN CAVITY
|
POSSIBLE
|
|
CONDENSATION RESISTANT
|
YES |
|
|
INTERNAL WALL
|
PP | |
|
OUTER WALL
|
Copper |
|
|
INSULATION
|
Air Gap |
|
|
INSULATION THICKNESS
|
10 mm |
|
|
DIAMETERS
|
⌀ 60 ÷ 100 |
|
|
TEMPERATURE LEVEL
|
120 °C
|
|
|
PRESSURE LEVEL
|
P1 = 200 Pa
|
|
|
GAS APPLIANCES
|
NO
|
|
GAS / DIESEL CONDENSING APPLIANCES
|
RECOMMENDED
|
|
OIL APPLIANCES
|
NO
|
|
WOOD-BURNING APPLIANCES
|
NO
|
|
PELLET APPLIANCES
|
NO
|
|
GAS COOKER HOODS
|
POSSIBLE
|
|
VENTILATION
|
POSSIBLE
|
|
OUTDOOR INSTALLATION
|
RECOMMENDED
|
|
INDOOR INSTALLATION
|
POSSIBLE
|
|
INSTALLATION IN CAVITY
|
POSSIBLE
|
Usual reference and designation
Product marking according to European standard
CE 0476 EN 14471.
T120 P1 W 2 O00 LE E UO
T120 H1 W 2 O00 LE E UO
Usage
Flue system and plastic flue serving condensing generators, kitchen hoods for domestic use.
Application
Indoor or outdoor installation
Available diameters - mm
80/100 - 100/120
EPDM gasket included and mounted.
