COAXIAL POLYPROPYLENE METAL: BIVENT PP/METAL
The BIVENT PP/METAL coaxial system is made up of coaxial rigid modular components, manufactured in polypropylene and protected by an external wall in white metal, which forms the containment for simple ventilation and/or the supply of combustion air to the generator, compliant with CE marking according to the EN 14471 European standards. The modular components have a classic calibrated male-female socket coupling with triple lip sealing gasket, compliant with the EN 14241-1 European standard. The system is suitable for extracting flue gases with a maximum operating temperature of up to 120 °C and a maximum pressure of 200 Pa.
DESIGNATIONS OF USE
Click on the designation to find out the related usage specifications
|
CONDENSATION RESISTANT
|
YES |
|
|
INTERNAL WALL
|
PP | |
|
OUTER WALL
|
White metal |
|
|
INSULATION
|
Ventilated air |
|
|
INSULATION THICKNESS
|
NO |
|
|
DIAMETERS
|
⌀ 60 ÷ 100 |
|
|
TEMPERATURE LEVEL
|
120 °C
|
|
|
PRESSURE LEVEL
|
H1 = 5000 Pa
|
|
 |
GAS APPLIANCES
|
NO
|
 |
GAS CONDENSING APPLIANCES
|
RECOMMENDED/div>
|
 |
OIL APPLIANCES
|
NO
|
 |
WOOD-BURNING APPLIANCES
|
NO
|
 |
APELLET APPLIANCES
|
NO
|
 |
GAS COOKER HOODS
|
POSSIBLE
|
|
VENTILATION
|
POSSIBLE
|
 |
OUTDOOR INSTALLATION
|
RECOMMENDED
|
 |
INDOOR INSTALLATION
|
RECOMMENDED
|
 |
INSTALLATION IN CAVITY
|
POSSIBLE
|
Usual reference and designation
Product marking according to European standard CE 0476 EN 14471.
T120 H1 W 2 O 00 LI E U0
Usage
Modular plastic flue systems - flues, masonry chimneys, steel chimneys, air vents - slaved to condensing generators.
Application
Indoor and outdoor installation.
Available diameters - mm - ON REQUEST
60/100 - 80/125 - 100/150
Gaskets included and mounted on both the
inner and external wall.
